SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller Discripton : Our roller range: Carrying roller, return roller, impact roller, vertical roller, self-alignment roller, side roller, through roller, roller group etc.About our factorySPD famous Conveyor Roller brand, 301 - 500 workers,&

Featured Products


SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller Discripton :



Our roller range:
Carrying roller, return roller, impact roller, vertical roller, self-alignment roller, side roller, through roller, roller group etc.


About our factory

SPD famous Conveyor Roller brand, 301 - 500 workers25000 m³non-dust workshop, Registered Capital: RMB 69,000,00020years experience, 35 Engineers and technicians , 28 Professional designers, 7 Senior engineers,18 engineers, two hours to Qingdao port.

Samples are acceptable. Rush order and large quantity are acceptable.

SPD Products details:

SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller Components & Installation Details
SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller  Some Whole Conveyor Projects we have done
SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller
SPD Conveyor Roller Certificate &Customers' Visit
SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller

SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller details:

1. Brand: SPD
2, Lift time: 50000hours
3, Production capacity: as usual 600pieces/day.
4. Roller Diameter: 76-219mm.
5. Roller Length: 190mm to 3500mm.
6. Roller tube: Q235 carbon steel,h
igh-precision ERW,                welded with DIN2394 Standard.

7. Shaft: 45# Cold drawing round steel in accordance with        DIN17100 and other equivalent standard, ISO h6                    precision

8. Bearing: Deep groove ball bearing 2RZ and 2Z with C3          clearance
9. Bearing brand: SKF,NSK, LYC etc.
10. Seals: Grease retaining inner seal with multi-stage                  labyrinth and retention cap with outboard rubbing                flinger seal
11. Color: according to your requirement.
12. Finish:
 Ordinary painting/hot galvanized                                     painting/Rubber/Steel screw/Galvanized.
13. Welding: Mixed gas shielded arc welding end .
14. Professional designing and inspection team.
15. Standard: ISO/BS/JIS/DIN//CEMA/Australia
16, Package:Export standard plywood cases with            waterproofing film

Standard DiameterLength scope ( mm)Bearings Type
(Min~Max)
Idler's Shell Wall Thickness
mmInch
63.52 1/2150~35002043.0mm~3.75mm
763150~3500204 2053.0mm~4.0mm
893 1/3150~3500204 2053.0mm~4.0mm
1024150~3500204 205 3053.5mm~4.0mm
1084 1/4150~3500204 205 305 3063.5mm~4.0mm
1144 1/2150~3500205 206 305 3063.5mm~4.5mm
1275150~3500204 205 305 3063.5mm~4.5mm
1335 1/4150~3500205 206 207 305 3063.5mm~4.5mm
1405 1/2150~3500205 206 207 305 3063.5mm~4.5mm
1526150~3500205 206 207 305 306 307 3084.0mm~4.5mm
1596 1/4150~3500205 206 207 305 306 307 3084.0mm~4.5mm
1656 1/2150~3500207 305 306 307 3084.5mm~6.0mm
177.87150~3500207 306 307 308 3094.5mm~6.0mm
190.77 1/2150~3500207 306 307 308 3094.5mm~6.0mm
1947 5/8150~3500207 307 308 309 3104.5mm~6.0mm
2198 5/8150~3500308 309 310

Main Features of SPD Belt Conveyor Roller Set, Conveyor Roller &Frame, Steel Roller

  • The bearing housing and steel tube are assembled  and welded  with a concentric automatic, welding machine.
  •  Cuting of the steel tube and bearing is performed     with the use of a digital aute device/machine/equipment.
  •  Fabrication of the roller is effected by an auto device and 100% tested for its concentricity.
  •  Roller and supporting components/materials are   manufactured to ISO/BS/JIS/DIN//CEMA standard.

About Rizhao Port Machine Engineering Co., Ltd

RZPMC is a comprehensive enterprise which engages in design, manufacture, installation and maintenance of the bulk-handling equipments. It is the wholly-owned subsidiary of the listed governmental company Rizhao port Co., Ltd.

It has the Second-level Qualification of the Machinery&Electrical Equipments installation Enterprise.

Our steel structures and frames production capacity is 160, 000 tons/year, the main products are belt conveyor, stacker-reclaimer machine, car loader machine, un-loader machine, etc. Widely used in ports, mining, food, power plants and other industries. We begin to make belt conveyor from the year 1993, and has lots of large contracts of manufactures and installation projects. In the year of 2005, we rely on our own technological superiority, self-design and manufacture the storage capacity of 9000 T/H of the stocker, as a national origination


Main Facilities & Capabilities

Cutting equipment
numberical control cutter machinesemi- manual cutter machines.

Forming equipment
300T friction punching machine160T punching machinemechanical plate shearing machine.

Plate roll equipment
hydraulic four rolles plate roll equipmentmechanical three rolles plate roll equipment.

Welding equipment
union melt welding, argon arc welding machinecarbon dioxide protection welding machineAC arc welding machine, direct current arc welding machine.

Test and MeasureInstruments: PaintFilmThickness Gauge, Buluowei hardness machine, Theodolite Magnetic Particle Flaw DetectorMetal gage, Ultrasonic Flaw Detector.

Heat treatment
electric furnace
carburizing furnace.

paint shop facilities
pneumatic
paint shop facilityhigh- pressure paint shop
facility.



Brand SPD
Specification SPD-76-219mm
CertificateISO/BV/SGS
StandardCEMA/JIS/DIN/Australia
ApplicationCoal mining industry, cement, steel, harbour etc.
Place of Origin Rizhao City , Shandong Province , China
Material FeatureWater, Wear, Dust resistance
Supply capacity 600pcs/day
Management system ISO 9001:2008,ISO 14001:2004,GB/T 28001-2001
